СКУ: 16329
КАТОДЕН ОТВОДИТЕЛ PRD1 25R 1P 350V WITH REM
-
Brand
Schneider Electric
-
Number of poles
1
-
Degree of protection (IP)
EV006405
-
System configuration TN-C
TRUE
-
System configuration DC
FALSE
-
System configuration TN
FALSE
-
System configuration IT
FALSE
-
Voltage protection level
1.5
-
System configuration TT
FALSE
-
System configuration TN-S
FALSE
-
Signalling at the device
EV000428
-
Max. conductor cross section solid (solid, stranded)
35
-
Max. conductor cross section flexible (fine-strand)
35
-
System configuration TN-C-S
FALSE
-
Mounting method
EV005503
-
System configuration other
FALSE
-
Integrated backup fuse
FALSE
-
Max. continuous voltage AC
350
-
Nominal voltage AC
230
-
Voltage switching spark gap technology
TRUE
-
Construction size
EV006974
-
Test class
EV007888
-
Remote signalling
TRUE
This Acti9 PRD1 is a modular surge arrester protecting 3P electrical installations against direct lightning strikes. The In nominal discharge current is 25kA. The Type 1 surge arrester is recommended for electrical installations in the service sector and industrial buildings protected by a lightning conductor. It is used to conduct the direct lightning current, propagating from the earth conductor to the network conductors. The surge arresters with "r" indication have remote transfer of the information "Cartridge to be replaced". The Uc maximum continuous operating voltage in common mode (between phase and earth) is 350VAC. The Up Voltage protection level in common mode (between phase and earth) is 1.5kV. The Ue rated operational voltage is 230VAC +/- 10%. The product colour is anthracite grey (RAL7016).The dimensions are (W) 108mm x (H) 90mm x (D) 71mm. The weight is 1.175kg. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 80°C. This product is compliant with EN 61643-11 and IEC 61643-11 standards.
