СКУ: A9L20300
Катоден отводител IPRD 20 20 KA 350V 3P SURGE ARRESTER
-
Brand
Schneider Electric
-
Number of poles
3
-
Degree of protection (IP)
EV006405
-
System configuration TN-C
TRUE
-
System configuration DC
FALSE
-
System configuration TN
FALSE
-
System configuration IT
FALSE
-
Voltage protection level
1.5
-
System configuration TT
FALSE
-
System configuration TN-S
FALSE
-
Signalling at the device
EV000428
-
Nominal voltage AC
400
-
Max. conductor cross section solid (solid, stranded)
35
-
System configuration TN-C-S
FALSE
-
Mounting method
EV005503
-
System configuration other
FALSE
-
Construction size
EV007026
-
Integrated backup fuse
FALSE
-
Max. continuous voltage AC
350
-
Test class
EV007888
-
Remote signalling
TRUE
-
Voltage protection level L-N
1.5
-
Voltage protection level N-PE
1.5
-
Max. conductor cross section flexible (fine-strand)
25
-
Voltage switching spark gap technology
FALSE
This Acti9 iPRD20r surge arrester protects 4P installations. It allows quick replacement of damaged cartridges. This Type 2 device is recommended for medium risk level and incoming panel board. It offers remote reporting of the "cartridge must be changed" message. It can be turned over to allow the phase/neutral/earth cables to enter through either the top or the bottom. The associated circuit breaker Isc breaking capacity can go up to 50kA. It is compatible with TT and TN-S earthing system. The Uc maximum continuous operating voltage in common mode (between phase and earth) is 460VAC. The Up Voltage protection level in common mode (L/PE or N/PE) is 1.8kV. The Ue rated operational voltage is 230VAC or 400VAC +/- 10%. The product colour is white (RAL9003).The dimensions are (W) 72mm x (H) 85mm x (D) 69mm. The weight is 450g. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 85°C. This product is compliant with EN 61643-11 and IEC 61643-11 standards.
