СКУ: LSS100300
SpaceLogic KNX BMS IP Gateway BACnet сертифициран
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Width in number of modular spacings
4
-
With LED indication
TRUE
-
Updateable
TRUE
-
IR interface
FALSE
-
Bus system KNX radio
FALSE
-
Bus system Powernet
FALSE
-
Web-Server
TRUE
-
Visualization
FALSE
-
Demounting protection
FALSE
-
Bus system LON
FALSE
-
Protocol
EV006511
-
Provider dependent
FALSE
-
Operating voltage
24
-
Voltage type
EV000461
-
Mounting method
EV006471
-
Bus system radio frequent
FALSE
-
Other bus systems
EV000494
-
Radio frequent bidirectional
FALSE
-
Bus system KNX
TRUE
-
Power consumption
2
-
Radio interface
FALSE
-
Model
EV006441
The SpaceLogic KNX BMS IP Gateway is a bidirectional multifunctional device that allows you integrate KNX installation with building automation devices. The main communication interface is KNX TP and IP supporting BACnet protocol. There are three components combined in one device: KNX IP router (max. 500 objects), KNX IP interface and DPSU choke power supply. The Gateway allows professional installers to deploy KNX installations more cost and time effectively thanks to features combination. Configuration and commissioning is straightforward and fast thanks to embedded Application simplifying the process. The architecture can be simpler because it is no longer necessary to use IP routers and KNX power supplies with respect to given parameters. The Gateway is designed for commercial installations and certified by BTL as Application Specific Controller (B-ASC) which ensures 100% compatibility and, at the same time, guarantees a seamless integration with any BACnet device.
