СКУ: CA3KN22JD

SCHNEIDER ELECTRIC Control relay, TeSys K, 2NO+2NC, 690V, 12VDC standard coil

  • Brand
    Schneider Electric
  • Connection type auxiliary circuit
    EV000415
  • Voltage type for actuating
    EV000460
  • Number of auxiliary contacts as normally closed contact
  • Number of auxiliary contacts as change-over contact
  • With LED indication
    FALSE
  • Suitable for manual operation
    FALSE
  • Interface
    FALSE
  • Mounting method
    EV010333
  • Rated operation current Ie, 400 V
    10
  • Number of auxiliary contacts as normally closed contact, delayed switching
  • Number of auxiliary contacts as normally open contact, leading
  • Rated control supply voltage Us at AC 50HZ
    42
  • Rated control supply voltage Us at AC 60HZ
    42
  • Number of auxiliary contacts as normally open contact
    2

TeSys K control relay, 4 contacts (2NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 220V DC control circuit with no inrush consumption, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC).
