СКУ: A9C15914
SCHNEIDER ELECTRIC Auxiliary contact, 1 OC
-
Brand
Schneider Electric
-
Width in number of modular spacings
1
-
Voltage type for actuating
EV000460
-
Rated voltage
240
-
With auto test for earth leakage function
FALSE
-
Suitable for max. number of poles main contact unit (total)
3
-
Installed at the factory
FALSE
-
Number of contacts as normally closed contact
-
Number of contacts as normally open contact
-
Number of contacts as change-over contact
-
Number of fault-signal switches
-
Suitable for max. current main contact unit
63
-
Device fitting
EV010066
-
Additional equipment
EV000154
-
Rated switch current
2
This Acti9 iATEt is reliable time delay auxiliary. It operates from 24VAC to 240VAC and 24VDC to 110VDC control voltage. Mounting is performed on the left of iTL impulse relay or iCT contactor with yellow clips. The degree of protection is IP20 and IP40 in an enclosure. It is DIN rail mountable. 5 time delays are possible, 1 for iTL and 4 for iCT. This product is compliant with EN/IEC 60669-2-2.
