Реверсивен ултракомпактен стартер, TeSys Hybrid, 3P, 500VAC, 0,75kW при 400V, 110 до 230VAC, пружинна клема | Spark & Co
  • 3D
|

СКУ: LZ2H2X43FU

Реверсивен ултракомпактен стартер, TeSys Hybrid, 3P, 500VAC, 0,75kW при 400V, 110 до 230VAC, пружинна клема

  • Brand
    Schneider Electric
  • Degree of protection (IP)
    EV006405
  • Voltage type for actuating
    EV000461
  • Rated control supply voltage Us at DC
    24
  • Supporting protocol for SERCOS
    FALSE
  • Supporting protocol for INTERBUS-Safety
    FALSE
  • Supporting protocol for AS-Interface Safety at Work
    FALSE
  • Supporting protocol for DeviceNet Safety
    FALSE
  • Supporting protocol for EtherNet/IP
    FALSE
  • Supporting protocol for Foundation Fieldbus
    FALSE
  • Supporting protocol for SafetyBUS p
    FALSE
  • Supporting protocol for PROFINET CBA
    FALSE
  • Supporting protocol for PROFINET IO
    FALSE
  • Supporting protocol for PROFIsafe
    FALSE
  • Supporting protocol for ASI
    FALSE
  • Supporting protocol for PROFIBUS
    FALSE
  • Supporting protocol for TCP/IP
    FALSE
  • Supporting protocol for CAN
    FALSE
  • Supporting protocol for INTERBUS
    FALSE
  • Supporting protocol for DeviceNet
    FALSE
  • Supporting protocol for Modbus
    FALSE
  • Supporting protocol for Data-Highway
    FALSE
  • Supporting protocol for LON
    FALSE
  • Supporting protocol for SUCONET
    FALSE
  • With transformer
    FALSE
  • Ambient temperature, upper operating limit
    70
  • Rail mounting possible
    TRUE
  • Supporting protocol for other bus systems
    FALSE
  • With fuse
    FALSE
  • Suitable for emergency stop
    TRUE
  • Number of auxiliary contacts as normally closed contact
  • Number of auxiliary contacts as normally open contact
  • Rated operation power at AC-3, 400 V
    0.75
  • Type of electrical connection of main circuit
    EV005752
  • Number of command positions
  • Release class
    EV008931
  • Type of motor starter
    EV004002
  • With short-circuit release
    FALSE
  • External reset possible
    TRUE
  • Temperature compensated overload protection
    TRUE
  • Number of indicator lights
    4
  • Rated operation current Ie
    2.4
  • Overload release current setting
    0.18
  • Rated operation current at AC-3, 400 V
    2.4
  • Width
    22.6
  • Depth
    113.4
  • Rated operation power at AC-3, 230 V, 3-phase
    0.37
  • Rated power, 460 V, 60 Hz, 3-phase
    0.75
  • Type of electrical connection for auxiliary- and control current circuit
    EV005752
  • Height
    107.5

EasyLogic T150 is a flexible RTU platform for energy automation applications. This controller range is embedded in an easy to use solution. This digital inputs acquisition block provides 16 inputs to acquire substation automation control status signals. Nominal voltage of the polarisation signal is 220Vdc. Acquisition block electronics includes millisecond timestamping and substation-grade galvanic isolation on all connections to field. All inputs are configurable to be managed as as single, double or slow counter inputs. Connection to field via direct pluggable terminal headers connected directly to the module. The product dimensions are 93 x 134 x 61 mm (Width x Height x Depth). This device is compliant with IEC 61850-3. Install on a DIN-rail and connect to a head unit and field I/O to acquire field signals. Offering good performance, medium scalability and full application modularity. EasyLogic T150 should satisfies the needs of RTUs in most energy automation use cases.
