СКУ: XACA491
Пулт за управл.- бутониера с двойно действ.бутони XACA491
-
Brand
Schneider Electric
-
Material housing
EV000139
-
Degree of protection (IP)
EV006421
-
Suitable for emergency stop
FALSE
-
Number of command positions
2
-
Colour housing cover
EV000234
-
Degree of protection (NEMA)
EV022254
-
Housing material quality
EV000154
-
Depth
71
-
Type of executable motions
EV002082
-
Width
52
-
Number of speeds
1
-
Height
295
-
Rated operation current Ie at AC-15, 600 V
1.2
This product is part of the Easy Harmony XA2 range, an offer of Ø 22mm plastic pushbuttons, switches and pilot lights. This selector switch comes with a long handle. It has 2 operating positions and functions with a stay-put mechanism. This selector switch provides a versatile interface for controlling machines. It has 1 NO contact with slow-break operation. This is a plastic selector switch with a metallic-look ring design bezel. This selector switch meets CE, CCC, and UKCA certifications and conforms to GB 14048.1, IEC 60947-1, GB 14048.5, and IEC 60947-5-1 standards. With its IP65 rating, the pushbutton is resistant to impact, dust, water, and vibration, making it suitable for operation in harsh environments. It is easily installed into a standard 22mm diameter panel cut-outs and connected to control circuits with screw-clamp connection. The Easy Harmony XA2 is a fit-for-purpose range at an affordable price without compromising on ease, robustness, availability, or services.
