СКУ: LV516440
прекъсвач EasyPact CVS160F, 36 kA, 415 VAC, 150 A номинален, магнитно MA изключващо у-во, 3P 3d
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Number of poles
3
-
Device construction
EV009211
-
Degree of protection (IP)
EV006415
-
Rated permanent current Iu
160
-
Width
105
-
Type of control element
EV000154
-
Rated operating voltage
220
-
Switch off technique
EV006116
-
With thermal protection
FALSE
-
Height
161
-
Phase failure sensitive
FALSE
-
Rated short-circuit breaking capacity lcu at 400 V, AC
36
-
Depth
86
-
With integrated under voltage release
TRUE
-
With integrated auxiliary switch
TRUE
-
Adjustment range undelayed short-circuit release
1350
This device is a rated current 150A circuit breaker from EasyPact CVS160F. The rated breaking capacity(Ics) is 36kA at 415VAC,and complete range with Ics=100%Icu. The version of breaker is 3poles frame with detection on 3poles, also accompanied MA trip unit for magnetic protection. It is conformed to standard IEC60947-2 for circuit breakers part. This device is certified for operation in pollution degree III environment as defined IEC60947-1& IEC60664-1, and respected for RoHs requirement as european environment directive EC/2002/95. It can be mounted by blackplate or Din rail,also through the door of class II switchboard without downgrading switchboard insulation. The front of toggle offers IP40 protection, but when it is equipped extended rotary handle inside the switchboard, additional IP54 protection degree for extended rotary handle. This series have slots for electrical auxiliaries(MN/MX/OF/SD),depending on the type of trip unit if rotary handle installed. The fixed dimension is 140mm width, 255mm height, 110mm depth.
