СКУ: EZ9EUA212

МОДУЛНО ТАБЛО ВГРАДЕН М-Ж 24М ОПУШ. ВРАТ

  • Brand
    Schneider Electric
  • Degree of protection (IP)
    EV006405
  • Width in number of modular spacings
    2
  • Number of poles (total)
    2
  • Release characteristic
    EV000084
  • Concurrently switching neutral conductor
    TRUE
  • Flush-mounted installation
    FALSE
  • Connectable conductor cross section multi-wired
    1
  • Number of protected poles
    1
  • Rated current
    10
  • Rated voltage
    230
  • Anti-nuisance tripping version
    FALSE
  • Rated fault current
    0.03
  • Surge current capacity
    0.25
  • Voltage type
    EV000460
  • Connectable conductor cross section solid-core
    1
  • Over voltage category
    3
  • Frequency
    EV008013
  • Ambient temperature during operating
    -5
  • Pollution degree
    2
  • Rated impulse withstand voltage Uimp
    4
  • Leakage current type
    EV000460
  • Current limiting class
    3
  • Built-in depth
    44.5
  • Rated insulation voltage Ui
    400
  • Rated short-circuit breaking capacity Icn according to EN 61009-1
    4.5
  • Disconnection characteristic
    EV003978
  • Rated short-circuit breaking capacity according to EN 61009
    6
  • With interlocking device
    FALSE

This Easy9 product is a low voltage miniature circuit breaker (MCB). It is a 3P circuit breaker with 3 protected pole, 16A In rated current, and a B tripping curve. The Icn rated short circuit breaking capacity is up to 6000A at 400VAC with an operating frequency of 50Hz conforming to IEC 60898-1 standard. It complies with IEC 60898-1 standard. This product has a protection against short circuit and a protection of cable against overloads. It has a fault tripping indication on the front panel by the position of the handle (O-I engraved). This product is dedicated for residential and small commercial buildings. It has an electrical endurance going up to 4000 cycles and a mechanical endurance going up to 10000 cycles. The Ue rated operational voltage is 400VAC with an operating frequency of 50Hz. The Ui rated insulation voltage is 500VAC. It has a Uimp rated impulse withstand voltage of 4kV conforming to IEC 60898-1 standard. It can be mounted on a DIN rail for modular installation. The operating temperature is from -25°C to +60°C. The storage temperature is from -40°C to +85°C.
