СКУ: SSM3A325P7

Harmony, Тиристорно модулно реле, 25 A, Реле за монтаж на DIN шина, превключване при нулево напрежение, вход 180…280 V AC, изход 48…600 V AC

  • Brand
    Schneider Electric
  • Voltage type for actuating
    EV000460
  • Number of phases
    3
  • Modular version
    TRUE
  • Operating voltage
    48
  • Switching at zero-crossing
    FALSE
  • Rated operation current Ie at AC-53a
    25
  • Rated operation current Ie at AC-51
    25
  • Rated operation current Ie at AC-53b
    25
  • Rated operation current Ie at AC-1
    25
  • Rated operation current Ie at AC-3
    25
  • Rated control supply voltage Us at AC 50HZ
    90
  • Rated control supply voltage Us at AC 60HZ
    90

This Harmony SSM solid state modular DIN rail single-phase relay is rated 6A, is controlled with a 4V to 32V DC input, has a rated load voltage of 48V to 600V AC with random voltage switching, ideal for inductive loads. It also has a visual indicator showing the status of its input. Built-in heatsink for maximum performance and less spare parts to manage. It is also silent and reliable thanks to the absence of moving contacts. Its clear schematic on the side of the socket enables easier wiring and maintenance.
