СКУ: NSYDLA84G
Модулно разпределително шаси 84 модула за NSYPLM86,NSYS3D86,NSYCRN86,NSYS3X86
-
Brand
Schneider Electric
-
With mounting plate
FALSE
-
Depth
110
-
With cover
FALSE
-
Type of cover
EV009916
-
With N-PE clamp
TRUE
-
Number of DIN-rails
3
-
Number of modular spacings per DIN-rail
16
-
Width
355
-
Height
455
DLM chassis for PanelSeT S3D, PanelSeT S3X and PanelSeT CRN enclosures The chassis is to be fixed on step slide and front of enclosure by fixing elements and back with supports location The width is 555mm The height is 753mm The depth is 101,5mm Number of 18mm modules is 112 (1 module = 2 steps = 18 mm) Number of horizontal rows is 4 The depth of the chassis can be adjusted in height from 40 to 85mm for DIN rail The product is made from grey steel (RAL 7035) The front has a grey (RAL 7035) color Number of cut-outs is 4 The kit is made up of 1 chassis structure, 4 front panels with 35mm DIN rails, 2 finish covers and 1 neutral/earth strip 2 x 16 mm² 5 x 6 mm² Anti-corrosion protection is ensured by an polyester powder coating
