СКУ: LU9MR1
Контролен клемен блок - за реверсивен двигателен стартер TeSys Ultra
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Rated operation power at AC-3, 400 V
5.5
-
Degree of protection (IP)
EV006405
-
Suitable for emergency stop
FALSE
-
Rated control supply voltage Us at AC 50HZ
24
-
Rated control supply voltage Us at AC 60HZ
24
-
Voltage type for actuating
EV000509
-
Rated control supply voltage Us at DC
24
-
Supporting protocol for SERCOS
FALSE
-
Supporting protocol for INTERBUS-Safety
FALSE
-
Supporting protocol for AS-Interface Safety at Work
FALSE
-
Supporting protocol for DeviceNet Safety
FALSE
-
Supporting protocol for EtherNet/IP
FALSE
-
Supporting protocol for Foundation Fieldbus
FALSE
-
Supporting protocol for SafetyBUS p
FALSE
-
Supporting protocol for PROFINET CBA
FALSE
-
Supporting protocol for PROFINET IO
FALSE
-
Supporting protocol for PROFIsafe
FALSE
-
Supporting protocol for ASI
FALSE
-
Supporting protocol for PROFIBUS
FALSE
-
Supporting protocol for TCP/IP
FALSE
-
Supporting protocol for CAN
FALSE
-
Supporting protocol for INTERBUS
FALSE
-
Supporting protocol for DeviceNet
FALSE
-
Supporting protocol for Modbus
FALSE
-
Supporting protocol for Data-Highway
FALSE
-
Supporting protocol for LON
FALSE
-
Supporting protocol for SUCONET
FALSE
-
Number of auxiliary contacts as normally closed contact
1
-
Number of auxiliary contacts as normally open contact
1
-
Rated conditional short-circuit current, type 1, 480 Y/277 V
10000
-
Rated conditional short-circuit current, type 2, 230 V
50000
-
Rated conditional short-circuit current, type 1, 600 Y/347 V
4000
-
With transformer
FALSE
-
Ambient temperature, upper operating limit
70
-
External reset possible
FALSE
-
Type of electrical connection for auxiliary- and control current circuit
EV000415
-
Rated conditional short-circuit current, type 2, 400 V
50000
-
Height
154
-
Number of command positions
3
-
Width
45
-
Coordination class according to IEC 60947-4-3
EV006627
-
Depth
126
-
Type of motor starter
EV004003
-
Rail mounting possible
TRUE
-
Supporting protocol for other bus systems
FALSE
-
With fuse
FALSE
-
With short-circuit release
TRUE
-
Rated operation current Ie
12
-
Rated operation current at AC-3, 400 V
12
-
Rated operation power at AC-3, 230 V, 3-phase
3
-
Rated power, 575 V, 60 Hz, 3-phase
5.5
-
Rated power, 460 V, 60 Hz, 3-phase
5.5
-
Number of indicator lights
TeSys U phase barrier for use with power bases LUB12, LUB32, LUB38, LUB120, LUB320, LUB380 or a limiter block LUALB1. It ensures a complementary electrical insulation between phases. Compulsory for use with a 690V AC network and with a 440 V AC network when assembling a UL508 type E compliant motor starter (Self Protected Starter).
