СКУ: C254MG250D
Изключвателно устройство TM250G DC, ComPacT NSX250 DC, 4 полюса, термомагнитни защити, генераторна защита, 250A rating
-
Brand
Schneider Electric
-
Number of poles
4
-
Rated permanent current Iu
200
-
Voltage type for actuating
EV009206
-
With ground fault protection function
FALSE
-
Short-circuit release function
EV003978
-
Type of motor protection
EV001281
-
Initial value of the undelayed short-circuit release - setting range
1000
-
End value adjustment range undelayed short-circuit release
2000
-
Overload release current setting
140
TM250G is a 4 poles 4d thermal-magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 250A rating thermal-magnetic trip unit is an optimum choice for generator protection applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. The rated current is 250A and the operational voltage is 750VDC. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.
