СКУ: C6341M500
изключвателно устройство MicroLogic 1.3M, ComPacT NSX630, 4 полюса 3D, електронна магнитна защита, моторна защита, 500A
-
Brand
Schneider Electric
-
Number of poles
3
-
Rated permanent current Iu
500
-
Type of motor protection
EV014005
-
Voltage type for actuating
EV009206
-
Short-circuit release function
EV003977
-
With ground fault protection function
FALSE
-
Overload release current setting
250
-
Initial value of the undelayed short-circuit release - setting range
6500
-
End value adjustment range undelayed short-circuit release
6500
This MicroLogic 6.3 E-M (Energy) is a 3 poles 3d electronic trip unit used on ComPacT NSX 630 circuit breakers. This 500A rating electronic trip unit is an optimum choice for motor protection applications. It embeds an adjustable long time protection against overloads. It provides also an adjustable short-time protection and a fixed instantaneous protection against short-circuits. It offers a phase unbalance or phase loss protection, and an additional and adjustable ground fault protection. MicroLogic 6.3 E-M indicates overloads with Alarm LEDs. The green Ready LED flashes if the circuit breaker is ready to trip. MicroLogic 6.3 E-M is equipped with a display module that gives energy measurement and allows fine adjustment settings. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.
