Високомощен контактор, TeSys Giga, 3 полюса (3NO), AC-3 <=440V 150A, разширена версия, 24…48V широколентова AC/DC намотка | Spark & Co
  • 3D
|

СКУ: LC1G150BEEA

Високомощен контактор, TeSys Giga, 3 полюса (3NO), AC-3 <=440V 150A, разширена версия, 24…48V широколентова AC/DC намотка

  • Brand
    Schneider Electric
  • Voltage type for actuating
    EV000509
  • Type of electrical connection of main circuit
    EV008864
  • Rated control supply voltage Us at DC
    100
  • Rated control supply voltage Us at AC 50HZ
    100
  • Rated control supply voltage Us at AC 60HZ
    100
  • Number of auxiliary contacts as normally closed contact
    1
  • Number of auxiliary contacts as normally open contact
    1
  • Modular version
    FALSE
  • Rated operation power at AC-3, 400 V
    110
  • Number of normally closed contacts as main contact
  • Number of normally open contacts as main contact
    3
  • Rated operation power NEMA
    150
  • Rated operation current Ie at AC-1, 400 V
    330
  • Rated operation current Ie at AC-3, 400 V
    225
  • Rated operation current Ie at AC-4, 400 V
    225
  • Rated operation power at AC-4, 400 V
    110

TeSys Deca contactor, 4 poles (2NO+2NC), for non-inductive load applications up to 80A/690V AC-1. It provides a 48V 50/60Hz AC coil, power connection by screw terminals, control connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (85mm width), DIN-rail mounting or screw fixing. Without build-in auxiliary contacts, side and front mounting auxiliary contact blocks available (to be ordered separately). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine).
