СКУ: 81683
Индустриален контакт за монтаж в табло, Mureva PK, прав, 63A, 3P+N+E, 400V, IP67
-
Brand
Schneider Electric
-
Material
EV000139
-
RAL-number
7035
-
Number of poles
4
-
Rated frequency
50
-
IEC-amperage
125
-
Connection system
EV001008
-
Identification colour
EV000233
-
Degree of protection (IP)
EV006423
-
Clock hour position
6
-
Military model
FALSE
-
Cable entry
EV000494
-
Flange size vertical
114
-
Flange size horizontal
110
-
Voltage according to EN 60309-2
EV009026
-
Rated voltage
380
-
Drill hole distance vertical
90
-
Drill hole distance horizontal
90
-
Angle of plug
EV000164
Experience the Mureva PK/PratiKa industrial wander socket with captive screws connection. It has a 3P+N+E outlet pole configuration. The cable entries are suitable for both flexible and rigid cables. The clock position of contact is 6h. Its Ue rated operational voltage is 380-415VAC at 50/60Hz and its Ie rated operational current is 125A. The dimensions of the wander socket are (W) 131mm x (H) 131mm x (D) 325mm. It reaches IP67 degree of protection. The fire resistance is 850°C. It is made up of self-extinguishing engineering polymer. The color of the product is grey (RAL 7035). Mureva PK industrial plugs and sockets expertly combine high performance with ease of installation and practicality. It is designed with providing exceptional levels of protection and ergonomics in mind. The product complies with the EN 60309-1, EN 60309-2 standards.
