СКУ: PKF32M744
Индустриален контакт 32 A - 3P + E - 480...500 V AC - IP67
-
Brand
Schneider Electric
-
Number of poles
3
-
Material
EV000139
-
RAL-number
7035
-
Connection system
EV001008
-
Degree of protection (IP)
EV006423
-
Military model
FALSE
-
Angle of plug
EV000164
-
Voltage according to EN 60309-2
EV009028
-
Identification colour
EV000206
-
Clock hour position
7
-
IEC-amperage
32
-
Cable entry
EV000154
This PratiKa industrial wander socket with captive screws connection is straight. It has 3P+E pole, rated current is 32A and the operating voltage is 500VAC. The dimensions of the wander socket are (W) 99mm x (H) 99mm. The degree of protection is IP67 and IK08. The fire resistance is 850°C. The cable entries are for flexible or rigid cables. The size of the cable entries in 32A is 11.5mm to 21mm for 2.5mm² to 10mm² cables. The color of the socket is grey (RAL 7035) with black easy identification of the operating voltage. The frequency is 50Hz or 60Hz. The clock position of contact is 7h.
