СКУ: 81140

Индустриален контакт, Mureva PK, 2P+E, 10/16 A, 250 V, IP65

  • Brand
    Schneider Electric
  • RAL-number
    7035
  • Degree of protection (IP)
    EV006421
  • Colour
    EV000270
  • Depth of device
    45.2
  • Mechanical coding
    FALSE
  • Duct installation
    FALSE
  • With terminal resistor
    FALSE
  • Width of device
    65
  • Height of device
    85
  • Colour coding
    FALSE
  • Type of fastening
    EV000766
  • Floor box/sub-floor mounted
    FALSE
  • Flush-mounted installation
    TRUE
  • With label space
    TRUE
  • Shielded buses
    FALSE
  • With dust cover
    TRUE
  • Connection type
    EV000173
  • Outlet direction
    EV000164
  • Shielded housing
    FALSE
  • Separate earthing connection
    FALSE
  • Assembly arrangement
    EV006349
  • With buses/couplings
    FALSE
  • Design suitable
    FALSE
  • Separate strain relief
    FALSE
  • Surface mounting
    TRUE
  • Number of modules (module system)
    1
  • Suitable for number of connectors
    1

This Mureva PK socket with completely loosened captive screws connection is wall mounted. It has 3P+E poles, rated current is 63A and the operating voltage is 200VAC to 250VAC. The dimensions of the base plate are (W) 104mm x (H) 255mm. The degree of protection is IP67 and IK08. The fire resistance is 850°C. The cable entries are for flexible or rigid cables. The size of the cable entries in 63A is 17mm to 31mm for 6mm² to 25mm² cables. The color of the socket is light grey (RAL 7035) with blue easy identification of the operating voltage. The frequency is 50Hz or 60Hz. The clock position of contact is 9h.
