СКУ: 82912
Индустриален контакт за монтаж в табло, Mureva PK, прав, 16A, 3P, 24…48V, IP44
-
Brand
Schneider Electric
-
Number of poles
3
-
Material
EV000139
-
RAL-number
7035
-
Connection system
EV001008
-
Military model
FALSE
-
Cable entry
EV000494
-
Angle of plug
EV000164
-
IEC-amperage
16
-
Degree of protection (IP)
EV006418
-
Flange size vertical
65
-
Flange size horizontal
65
-
Rated voltage
20
-
Voltage according to EN 60309-2
EV009021
-
Identification colour
EV000235
-
Drill hole distance horizontal
52
-
Rated frequency
401
This Mureva PK socket with completely loosened captive screws connection is straight panel mounted. It has 3P poles, rated current is 16A and the operating voltage is 20VAC to 25VAC or 40VAC to 50VAC. The dimensions of the base plate are (W) 65mm x (H) 65mm. The degree of protection is IP44 and IK08. The fire resistance is 850°C. The cable entries are for flexible or rigid cables. The cross section of the cables in 16A is 1mm² to 2.5mm². The color of the socket is light grey (RAL 7035) with green easy identification of the operating voltage. The frequency is 401Hz to 500Hz. The clock position of secondary keyway is 11h.
