СКУ: C40H3
Автоматичен прекъсвач NSX400H 70kA AC 3P 400A без вкл. изключвателно устройство
-
Brand
Schneider Electric
-
Rated control supply voltage Us at DC
24
-
Type of motor protection
EV014005
-
Voltage type for actuating
EV009206
-
Overload release current setting
252
-
Rated permanent current Iu
3200
-
With ground fault protection function
FALSE
-
Initial value of the undelayed short-circuit release - setting range
378
-
Short-circuit release function
EV003978
-
End value adjustment range undelayed short-circuit release
32000
This device is an electronic control unit MicroLogic 2.0E for ComPacT NS630-NS1600 circuit breakers, withdrawable and manually operated. ComPacT NS is designed to optimize space and breaking capacity, it is an optimal choice for all standard and specific applications. MicroLogic control unit has a new design and colour (dark grey). The control unit rating is fixed by an additional long time rating plug which has to be ordered separately through the product selector. This control unit has basic protections and is designed to protect power circuits and loads. MicroLogic 2.0E control unit provides an overload protection (true rms and adjustable long time protection), and an instantaneous short-circuit protections. It provides also an adjustable instantaneous protection against short-circuits (ANSI Code 50). The control unit rating is fixed by an additional long time rating plug which has to be ordered separately through the product selector. MicroLogic 2.0E is equipped with a digital LCD screen and displays energy (energy meter) and rms values of currents. MicroLogic E type indicates overloads with an alarm LED and is able to display the trip cause through 4 others LEDs. MicroLogic E type is equipped with a digital LCD screen that displays the active energy with 2% accuracy. ComPacT is compliant with IEC 60947-1 and IEC60947-2 international standards. ComPacT NS can be integrated within Schneider Electric EcoStruxure Power architecture. ComPacT NS is part of the global Schneider Electric Environmental Program.
