СКУ: GV5P150H

SCHNEIDER ELECTRIC Motor circuit breaker 3P, 150A, HS code: 85362090, COO: FR, 2.2kg /PO:41125876/

  • Brand
    Schneider Electric
  • Type of electrical connection of main circuit
    EV000415
  • Number of poles
    3
  • Rated operating voltage
    690
  • Rated permanent current Iu
    80
  • Rated operation power at AC-3, 400 V
    37
  • Degree of protection (IP)
    EV006415
  • With integrated under voltage release
    FALSE
  • With integrated auxiliary switch
    FALSE
  • Phase failure sensitive
    TRUE
  • Device construction
    EV009311
  • With thermal protection
    TRUE
  • Rated operation power at AC-3, 230 V
    22
  • Type of control element
    EV001252
  • Width
    81
  • Height
    155
  • Switch off technique
    EV000101
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    25
  • Depth
    116
  • Overload release current setting
    40
  • Adjustment range undelayed short-circuit release
    1360

TeSys GV motor circuit breaker, 3 poles (3P), 220A/690V, for protection of 3-phase motors 90-110kW at 400V. It provides thermal magnetic protection and additional protections, breaking capacity Icu 36kA, start-stop control by rotary handle, connection for bars or cables with lugs (direct connection of cables with additional connectors). Thermal protection adjustable by dials with a setting current Ir in range 100-220A and a selectable tripping class 5, 10 or 20, magnetic protection at 15 In. Additional protections with fixed pick-up include short time delay protection Isd at 13 Ir, phase unbalance and loss protection. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine).
