СКУ: EZ9A34223
Звънец Easy9 Bell 230V
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Width in number of modular spacings
2
-
Number of poles (total)
2
-
Release characteristic
EV000084
-
Concurrently switching neutral conductor
TRUE
-
Flush-mounted installation
FALSE
-
Connectable conductor cross section multi-wired
1
-
Number of protected poles
1
-
Rated current
16
-
Rated voltage
230
-
Anti-nuisance tripping version
FALSE
-
Rated fault current
0.03
-
Surge current capacity
0.25
-
Voltage type
EV000460
-
Connectable conductor cross section solid-core
1
-
Over voltage category
3
-
Frequency
EV008013
-
Ambient temperature during operating
-5
-
Pollution degree
2
-
Rated impulse withstand voltage Uimp
4
-
Leakage current type
EV000460
-
Current limiting class
3
-
Built-in depth
44.5
-
Rated insulation voltage Ui
400
-
Rated short-circuit breaking capacity Icn according to EN 61009-1
4.5
-
Disconnection characteristic
EV003978
-
Rated short-circuit breaking capacity according to EN 61009
6
-
With interlocking device
FALSE
This Easy9 XP is a modular residual current breaker with overcurrent protection (RCBO). It is a 1P+N circuit breaker with 1 protected pole, 16A In rated current and C tripping curve. The earth leakage protection class is AC type with a sensitivity of 30mA. The earth-leakage protection time delay is instantaneous. The Icn rated short circuit breaking capacity is up to 6000A according IEC 61009-1 standard. This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards. It can be fitted instead of a miniature circuit breaker for complete protection of one circuit. This product is compliant with IEC 61009-1 standard. It has an electrical endurance going up to 4000 cycles and a mechanical endurance going up to 10000 cycles. The Ue operational voltage is 230VAC. It is DIN rail mountable. The width in 9mm pitches is 4. The dimensions are (W) 36mm x (H) 82mm x (D) 70.5mm. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is from -5°C to 60°C. The storage temperature is from -40°C to 85°C.
