СКУ: 15331
Времереле IH 7D 18MM
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Concurrently switching neutral conductor
FALSE
-
Frequency
50
-
Built-in depth
47
-
Rated insulation voltage Ui
690
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
50
-
Additional equipment possible
TRUE
-
Rated impulse withstand voltage Uimp
8
-
Rated voltage
400
-
Release characteristic
EV000084
-
Voltage type
EV000509
-
Flush-mounted installation
FALSE
-
Explosion-proof
FALSE
-
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
25
-
Connectable conductor cross section solid-core
1.5
-
Over voltage category
4
-
Ambient temperature during operating
-30
-
Connectable conductor cross section multi-wired
1
-
Pollution degree
3
-
Rated current
40
-
Width in number of modular spacings
4.5
-
Number of poles (total)
3
-
Number of protected poles
3
The 4 modules selector switches are designed for DIN rail installation in enclosures or cubicles. The ammeter selector switch uses a single ammeter (by means of current transformers) for successive measurement of the currents of a three-phase circuit. Electrical durability of 1,000,000 operations, and mechanical durability of 2,000,000 operations for an utilization category type AC21A-3. This product is calibrated for 10A circuit rating. 4 contacts for phase 1, 2, 3 or none. Complient to standards IEC/EN 60947-3. Ingress Protection IP66 on front, and IP20 on the back at terminal level. Product dimensions are 60mm in height, 36mm in width and 75mm in depth.
