СКУ: A9V54225

Vigi iC60 - допълнителен блок за земни утечки - 2P - 25A - 300mA - A тип

  • Brand
    Schneider Electric
  • Degree of protection (IP)
    EV006405
  • Number of poles
    2
  • Connectable conductor cross section multi-wired
    1
  • Pollution degree
    3
  • Nominal voltage
    230
  • Nominal current
    63
  • Delay adjustable
    FALSE
  • Frequency
    EV008015
  • Rated fault current
    0.3
  • Rated fault current adjustable
    FALSE
  • Anti-nuisance tripping version
    FALSE
  • Surge current capacity
    0.25
  • Rated impulse withstand voltage Uimp
    6
  • Connectable conductor cross section solid-core
    1
  • Rated insulation voltage Ui
    500
  • Ambient temperature during operating
    -5
  • Leakage current type
    EV000460
  • With interlocking device
    FALSE
  • Max. delay time

This Acti9 Vigi iC40 is a modular add-on residual current devices. It is a 1P+N and rated current is 25A. The earth leakage protection class is AC type with a sensitivity of 300mA and a voltage independent technology. This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards. A VisiTrip window is here to indicate a fault tripping by a red mechanical indicator on the front face. This product is compliant with EN/IEC 61009-2-1 standard. Electrical endurance goes up to 10000 cycles. Mechanical endurance goes up to 20000 cycles. The Ue rated operational voltage is 230VAC. The Ui rated insulation voltage is 400VAC. The Uimp rated impulse withstand voltage is 4kV. The pollution degree is 3. It can be mounted on DIN rail. The width in 9mm pitches is 2. The product color is white (RAL9003). The dimensions are (W) 36mm x (H) 95mm x (D) 74mm. The weight is 90g. The degree of protection is IP20 and IP40 in an enclosure. The operating temperature is -5°C to 60°C. The storage temperature is -40°C to 85°C.
