СКУ: 65317
Външен нулев проводник, фиксиран ComPact NS630b до NS1600 с MicroLogic P
-
Brand
Schneider Electric
-
Rated permanent current Iu
1600
-
Type of motor protection
EV014005
-
Voltage type for actuating
EV009206
-
Overload release current setting
252
-
Short-circuit release function
EV003977
-
With ground fault protection function
FALSE
-
Initial value of the undelayed short-circuit release - setting range
3200
-
End value adjustment range undelayed short-circuit release
24000
This Mureva PK socket with completely loosened captive screws connection is wall mounted. It has 3P+E poles, rated current is 125A and the operating voltage is 380VAC to 415VAC. The dimensions of the base plate are (W) 114mm x (H) 340mm. The degree of protection is IP67 and IK08. The fire resistance is 850°C. The cable entries are for flexible or rigid cables. The size of the cable entries in 125A is 26mm to 48mm for 16mm² to 70mm² cables. The color of the socket is light grey (RAL 7035) with red easy identification of the operating voltage. The frequency is 50Hz or 60Hz. The clock position of contact is 6h.
