СКУ: A9MEM3150
Трифазен електромер kWh 63A MODBUS
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Width
90
-
Width in number of modular spacings
5
-
Frequency
50
-
Degree of protection (NEMA)
EV000599
-
Depth
69
-
Model
EV010943
-
Pulse output
EV003671
-
Escapement mechanism
FALSE
-
Energy type
EV010944
-
Tariff type
EV009223
-
Type of indication
EV005572
-
Mounting method
EV006471
-
With lock code
FALSE
-
Type of meter
EV000101
-
Nominal voltage (Un) N-L
100
-
Measurement type load profile
FALSE
-
EEC40 signature
FALSE
-
Suitable for
EV011029
-
Height
95
-
Max. current (Imax)
6
-
Calibrated
FALSE
-
Approval
EV010950
-
Type of interface
EV000494
-
Pulse rate
-
Accuracy class
EV000084
-
Number of positions total (counter)
9
-
Pole type
EV011974
-
Nominal voltage (Un) L-L
173
-
Nominal current (In)
5
-
Pulse type
EV010952
The Acti9 iEM3000 series energy meters offer an attractive range of three-phase DIN rail-mounted energy meters with an LCD display. Additional local signaling includes green LED power-on indicator, flashing yellow LED for accuracy checking, an overload alarm and communication indicators. This meter can be used in sub-billing applications and supports 4 tariff schedules. The meter provides the following accuracy classes: Active Energy: class 0.5S per IEC 62053-22, Active Energy: class C per EN 50470-3 and Active Energy: class 0.5S per IEC 61557-12. The meter will measure Active and Reactive Power, Active and Reactive Energy, Voltage and Current. With four quadrant Energy measurement. Designed for 50Hz or 60Hz networks, supply voltage can range from 100 to 277VAC or 173 to 480VAC. The rated current goes through a 1A or 5A transfomer to be measured in this meter and will support Single Phase and Neutral, Three Phase and Three Phase and Neutral configurations. Communication protocol is M-Bus with screw terminal support. There is one programmable digital input and one programmable digital output that can be used as a pulsed output. Certifications include EAC, CE, UL and MID. Product dimensions are as follows: width 3.54 in (90 mm), depth 2.72in (69 mm), height 3.74 in (95 mm) and product weight 9.17 oz (260 g).
