СКУ: A9S65163
Тов. прекъсвач iSW 1P 63A /A9S60163/
-
Brand
Schneider Electric
-
Number of contacts as normally open contact
1
-
Number of poles
1
-
Degree of protection (IP)
EV006405
-
Width in number of modular spacings
1
-
Rated current
63
-
Voltage type
EV000460
-
Rated voltage
240
-
With signal lamp
FALSE
-
Imprint/indication
EV000154
-
Number of contacts as normally closed contact
-
Number of contacts as change-over contact
-
Colour calotte
EV000270
-
Forced segregation (according to DIN VDE 0113)
TRUE
-
Switching function
EV000397
-
Built-in depth
75.5
-
Rated switching capacity
5
-
Short-circuit breaking capacity (Icw)
1.26
-
Min. rated voltage
240
This Acti9 iID is a modular and reliable residual current circuit breaker (RCCB). It is a 4P circuit breaker with 25A In rated current, 30mA earth leakage sensitivity and AC type protection class. This product protects against electrical shock by direct or indirect contact and fire hazards. It performs the function of disconnection of electrical circuits in case of earth fault. Its unique Visitrip indicator reduces intervention time by showing the faulty device with a mechanical indicator on front face. This product also has a VisiSafe window with a green strip on the toggle indicating full opening of the poles allowing downstream maintenance. This product is compliant with EN/IEC 61008-1 standard. The (Im/IΔm) rated breaking and making short circuit capacity is 1500A. The (Inc/IΔc) conditional rated short circuit current is 10kA. It has an electrical endurance going up to 15000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 380VAC to 415VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The frequency is 50Hz or 60Hz. It is DIN rail mountable. The width in 9mm pitches is 8. The product colour is white (RAL9003). The dimensions are (W) 72mm x (H) 91mm x (D) 73.5mm. The weight is 0.37kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is from -5°C to 60°C. The storage temperature is from -40°C to 85°C.
