СКУ: A9A26905
Спомагателен контакт, Acti9 A9A, iOF, 1 C/O, 100mA - 6A, 24VAC - 415VAC, 24VDC - 130VDC, горна връзка
-
Brand
Schneider Electric
-
Number of contacts as normally open contact
1
-
Number of contacts as normally closed contact
1
-
With auto test for earth leakage function
FALSE
-
Width in number of modular spacings
0.5
-
Suitable for max. number of poles main contact unit (total)
4
-
Voltage type for actuating
EV000461
-
Number of fault-signal switches
1
-
Installed at the factory
FALSE
-
Number of contacts as change-over contact
-
Rated voltage
24
-
Device fitting
EV009775
-
Additional equipment
EV009833
-
Suitable for max. current main contact unit
63
-
Rated switch current
0.1
This Acti9 Reflex iC60N is a low voltage integrated control circuit breaker. It is a 2P circuit breaker with protected poles, 40 A rated current and B tripping curve. As circuit breaker, its breaking capacity, according to IEC/EN 60947-2, is 20kA at 220VAC to 240VAC, and 10kA at 380VAC to 415VAC. As a circuit breaker, it protects circuits against short circuit and overload currents, disconnection in the industrial sector. It can control a device remotely by latched and/or impulse-type order according to the 2 operating modes to be chosen by the user. Resetting after a fault is performed manually by the resetting handle. The Ti24 interface allows direct interfacing of the Reflex iC60 with a PLC. It allows to execute remote control, to indicate the state of the control circuit and circuit breaker state information, to connect it to the Acti9 Smartlink thanks to the prefabricated cables. Electrical endurance goes up to 50000 cycles. Mechanical endurance to 50000 cycles. The Ui rated insulation voltage is 500VAC. It can be mounted on DIN rail for modular installation. Its width is 9 modules of 9mm. The product color is white (RAL9003). The dimensions are (W) 81 mm x (H) 84 mm x (D) 77 mm. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. It becomes IP40 once in modular enclosure with insulation class II.
