СКУ: ATS22C41S6U
SCHNEIDER ELECTRIC Soft starter Altistart 22, control 110V, 208-575V, 125-350hp
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Voltage type for actuating
EV000509
-
Rated control supply voltage Us at AC 50HZ
110
-
Rated control supply voltage Us at AC 60HZ
110
-
Release class
EV000154
-
With display
FALSE
-
Rated operating voltage Ue
208
-
Torque control
TRUE
-
Function
EV014006
-
Integrated motor overload protection
TRUE
-
Rated surrounding temperature without derating
40
-
Internal bypass
TRUE
-
Rated operation current Ie at 40 °C Tu
410
-
Rated power three-phase motor, inline, at 230 V
110
-
Rated power three-phase motor, inline, at 400 V
220
This Altistart 22 soft starter can feed 3-phase asynchronous motors in supply line connection. It has a rating of 410A, a rated power from 125HP to 350HP and a rated voltage from 230V to 575V AC. It is designed for simple and complex machines such as centrifugal and piston pumps, fans, screw compressors and material handling equipment. Slim form factor improves versatility; allows mounting in frames of any kind of machines. It features an Integrated bypass, this reduces noise and decreases heat dissipation. Compatibility with SoMove software allows configurations and settings to be easily transferred, meaning spares can be quickly installed. It provides smooth starting for your machinery, avoiding mechanical stresses and extending their service life.
