СКУ: GV2RT14

SCHNEIDER ELECTRIC Motor circuit breaker, TeSys GV2, 3P, 6-10A, thermal magnetic

  • Brand
    Schneider Electric
  • Type of electrical connection of main circuit
    EV000415
  • Number of poles
    3
  • Rated operating voltage
    690
  • Rated operation power at AC-3, 400 V
    4
  • Degree of protection (IP)
    EV006405
  • With integrated under voltage release
    FALSE
  • Width
    45
  • With integrated auxiliary switch
    FALSE
  • Phase failure sensitive
    TRUE
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    100
  • Height
    89
  • Device construction
    EV009311
  • Rated permanent current Iu
    10
  • Rated operation power at AC-3, 230 V
    2.2
  • Switch off technique
    EV009462
  • With thermal protection
    TRUE
  • Overload release current setting
    6
  • Type of control element
    EV001252
  • Depth
    78.5
  • Adjustment range undelayed short-circuit release
    200

TeSys GV motor circuit breaker, 3 poles (3P), 10A/690V, for high starting current peak motor applications 3-4kW/400V. It provides a thermal-magnetic protection with a thermal setting range 6-10A, a magnetic tripping level at 20xIn, high breaking capacity Icu 100kA/400V. Connection by screw clamp terminals. Start-stop control by toggle guaranteed for 100 000 cycles AC-3. It can be used for protection of 3-phase transformer applications. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine).
