СКУ: GV4PE80B

SCHNEIDER ELECTRIC Motor circuit breaker, 3P, 80A, Icu 25kA, thermal magnetic, Everlink terminals

  • Brand
    Schneider Electric
  • Type of electrical connection of main circuit
    EV000415
  • Number of poles
    3
  • Rated operating voltage
    690
  • Degree of protection (IP)
    EV006415
  • With integrated under voltage release
    FALSE
  • Rated operation power at AC-3, 400 V
    1.5
  • With integrated auxiliary switch
    FALSE
  • Rated operation power at AC-3, 230 V
    0.75
  • Phase failure sensitive
    TRUE
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    100
  • Device construction
    EV009311
  • With thermal protection
    TRUE
  • Type of control element
    EV001252
  • Width
    81
  • Height
    155
  • Switch off technique
    EV000101
  • Rated permanent current Iu
    3.5
  • Overload release current setting
    1.4
  • Adjustment range undelayed short-circuit release
    60
  • Depth
    116

TeSys GV motor circuit breaker, 3 poles (3P), 150A/690V, for protection of 3-phase motors 55-75kW at 400V. It provides thermal magnetic protection and additional protections, breaking capacity Icu 70kA, start-stop control by rotary handle, connection for bars or cables with lugs (direct connection of cables with additional connectors). Thermal protection adjustable by dials with a setting current Ir in range 70-150A and a selectable tripping class 5, 10 or 20, magnetic protection at 15 In. Additional protections with fixed pick-up include short time delay protection Isd at 13 Ir, phase unbalance and loss protection. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine).
