СКУ: 18608
SCHNEIDER ELECTRIC Miniature circuit breaker Acti9 NG125a, 4P, 100A, C curve, 16kA
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Integrated short-circuit protection
FALSE
-
Leakage-current free
FALSE
-
Nominal discharge surge current (8/20)
25
-
System configuration DC
FALSE
-
System configuration IT
FALSE
-
Voltage protection level
1.5
-
System configuration TN-S
FALSE
-
Signalling at the device
EV000428
-
System configuration TN-C-S
FALSE
-
System configuration other
FALSE
-
Integrated backup fuse
FALSE
-
Max. continuous voltage AC
350
-
System configuration TN-C
FALSE
-
System configuration TN
TRUE
-
System configuration TT
TRUE
-
Nominal voltage AC
230
-
Mounting method
EV007107
-
With remote signalling contact
FALSE
-
Construction size
EV000154
-
Category type 2
FALSE
This Acti9 PRD1 is a modular surge arrester protecting 1P electrical installations against direct lightning strikes. The In nominal discharge current is 25kA. The Type 1 surge arrester is recommended for electrical installations in the service sector and industrial buildings protected by a lightning conductor. It is used to conduct the direct lightning current, propagating from the earth conductor to the network conductors. The surge arresters with "r" indication have remote transfer of the information "Cartridge to be replaced". The Uc maximum continuous operating voltage in common mode (between phase and earth) is 350VAC. The Up Voltage protection level in common mode (between phase and earth) is 1.5kV. The Ue rated operational voltage is 230VAC +/- 10%. The product colour is anthracite grey (RAL7016).The dimensions are (W) 35.8mm x (H) 90mm x (D) 70mm. The weight is 303g. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 80°C. This product is compliant with EN 61643-11 and IEC 61643-11 standards.
