SCHNEIDER ELECTRIC Mechanical time switch Acti 9, IH, 24h, without memory

  • Brand
    Schneider Electric
  • Number of contacts as normally open contact
    1
  • Width in number of modular spacings
    1
  • Mounting method
    EV000242
  • Frequency control voltage 1
    50
  • Release-delay
    1
  • Built-in depth
    68
  • Max. load fluorescent lamp (parallel compensated)
    1300
  • Voltage type of supply voltage
    EV000460
  • Max. incandescent lamp load
    2300
  • Max. load fluorescent lamp
    2300
  • Max. load fluorescent lamp (Duo circuit)
    2300
  • Control voltage 1
    230
  • Type of control voltage 1
    EV000460
  • Push button glow-lamp current
    50
  • Rated switch current
    16
  • Supply voltage
    230
  • Pre-warning of switching-off
    EV000494
  • Wiring system
    EV005718
  • Repetitive
    EV000494
  • Max. switching current (cos phi = 0.6)
    10
  • Number of contacts as change-over contact
  • Function
    EV000154
  • Number of contacts as normally closed contact
  • Current surge function selectable
    FALSE

IH mechanical time switch. Width of 18mm (2 modules of 9mm). Automatically switches On and Off loads according to the program entered by the user on daily level. Swiching cycle is 24 h (daily). The minimum time between 2 switching operations is 15 minutes with the number of 48 On and 48 Off. Savings on mains cut off with battery reserve: 100 hours. Manual override is possible. 1 channel output.
