СКУ: RM35BA10
Pump relay 10A 1CO 208 480V
-
Brand
Schneider Electric
-
Type of electric connection
EV000415
-
Depth
72
-
Number of contacts as change-over contact
1
-
With detachable clamps
FALSE
-
Voltage type for actuating
EV000509
-
Height
90
-
Rated control supply voltage Us at AC 50HZ
208
-
Rated control supply voltage Us at AC 60HZ
208
-
Width
35
-
Max. permitted off-delay time
10
-
Min. adjustable off-delay time
0.1
-
Single-phase hysteresis possible
TRUE
-
Three-phase hysteresis possible
TRUE
-
Three-phase over current possible
TRUE
-
Three-phase under current possible
TRUE
-
External current transformer
FALSE
-
Current measuring range
1
-
Single-phase over current possible
TRUE
-
Single-phase under current possible
TRUE
-
Function DC-current hysteresis
FALSE
-
Contains function DC-voltage over current
FALSE
-
Contains function DC-voltage under current
FALSE
-
Min. adjustable delay-on energization time
1
-
Number of contacts as normally closed contact
-
Number of contacts as normally open contact
-
Max. permitted delay-on energization time
60
This Harmony RM35-BA control relay allows monitoring of pump control. This modular pump control relay is ideal for monitoring of electrical values in industrial and building control panels. It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water. It has one of market medium form-factors with 35mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 3-pole DIN device. It also offers a selectable memory function, integral LED for indicating control status, sealable cover, with simple and precise settings with screw trimmers. It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting. Multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC.
