СКУ: LVSSDT824
PrismaSeT S Transparent Door 8R24M
-
Brand
Schneider Electric
-
Material
EV000139
-
Colour
EV000202
-
EMC-version
FALSE
-
Degree of protection (IP)
EV006415
-
Version as door for disconnecting switch interlocking
FALSE
-
Version as glazed door
FALSE
-
Height
300
-
Model
EV009234
-
Depth
20
-
Width
426
It is a direct rotary handle for ComPacT NSX 400/630 and PowerPact Multistandard H/J frames devices. It is suitable for isolation and it is used for standard applications. It maintains the access to trip unit settings and to the push to trip button. It is equipped with a standard black handle. There is an indication of the three device positions O (OFF), I (ON) and tripped. The degrees of protection are IP40 and IK07. This rotary handle is padlockable in the OFF position using 1 to 3 padlocks not supplied (shackle diameter 5 to 8mm). As an option, it is possible to install a Ronis or Profalux keylock on the base of the handle to obtain the same function as with a padlock.
