СКУ: EZ9F35125
Авт. прекъсвач EASY9 XP 1P 6000 C 25А
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Width in number of modular spacings
2
-
Frequency
50
-
Number of poles (total)
2
-
Number of protected poles
2
-
Rated voltage
400
-
Release characteristic
EV000084
-
Concurrently switching neutral conductor
TRUE
-
Flush-mounted installation
FALSE
-
Explosion-proof
FALSE
-
Connectable conductor cross section multi-wired
1
-
Rated current
25
-
Ambient temperature during operating
-25
-
Voltage type
EV000460
-
Connectable conductor cross section solid-core
1
-
Over voltage category
3
-
Pollution degree
2
-
Rated impulse withstand voltage Uimp
4
-
Built-in depth
45
-
Additional equipment possible
FALSE
-
Current limiting class
3
-
Rated insulation voltage Ui
440
-
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
6
-
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
6
This Easy9 TL product is a modular impulse relay. This 1P device has 1 normally open contact. The In rated current is 16A, 250VAC operating voltage and it operates with 230VAC control voltage. Electrical endurance goes up to 200000 cycles. The switching frequency is 5 switching operations/minute or 100 switching operations/day. The duration of the command order should be between 50ms to 200ms. It allows remote control of single phase circuits. It is mainly used for lighting control applications. The Ui rated insulation voltage is 250VAC. It is DIN rail mountable. The product color is light grey (RAL7035). The dimensions are (W) 18mm x (H) 81mm x (D) 64mm. Product weight is 105g. The degree of protection is IP20 and IP40 in an enclosure. The operating temperature is from -20°C to 50°C. The storage temperature is from -40°C to 70°C . This product is compliant with IEC/EN 60669-2-2 standard.
