Основа за универсален димер за LED осветление | Spark & Co
  • 3D
|

СКУ: MTN5134-0000

Основа за универсален димер за LED осветление

  • Brand
    Schneider Electric
  • Transparent
    FALSE
  • Frequency
    50
  • Nominal voltage
    230
  • Connection type
    EV001008
  • Mounting method
    EV000383
  • Compatible with Apple HomeKit
    FALSE
  • Compatible with Google Assistant
    FALSE
  • Compatible with Amazon Alexa
    FALSE
  • Surface protection
    EV006034
  • IFTTT support available
    FALSE
  • Halogen free
    TRUE
  • Material
    EV000154
  • Suitable for degree of protection (IP)
    EV006405
  • Type of fastening
    EV006353
  • Material quality
    EV000154
  • Assembly arrangement
    EV000078
  • Min. depth of built-in installation box
    40
  • Depth of device
    29
  • Core cross section
    1.5
  • Method of operation
    EV000251
  • Type of load
    EV011953
  • Applicable with infrared button
    FALSE
  • Applicable with movement sensor
    FALSE
  • Dimming phase cut-on
    TRUE
  • Dimming phase cut-off
    TRUE
  • Serial dimmer
    FALSE
  • Applicable with presence indicator
    FALSE
  • App control via Bluetooth
    FALSE
  • Applicable with time switch/timer
    FALSE
  • Substation input
    TRUE
  • Applicable with transmission button
    FALSE
  • Max. switching power LED
    200
  • Width of device
    74
  • Light value memory
    FALSE
  • Nominal power inductive load
    4
  • Nominal power resistive load
    10
  • Nominal power capacitive load
    4
  • Height of device
    74
  • Applicable with button
    FALSE

Schneider Electric Merten rotary dimmer MTN5134-0000 is a is a 2-way universal rotary dimmer. And the control type of this rotary dimmer is turn and push-button. It is 74 mm in width, 74 mm in height, 47 mm in depth, with an embedding depth of 29 mm And the product weighs 0.09 kg. In addition, the rated operational voltage of this device is 230V. The fixing mode of this device is by screws and claws. Its matching mounting box can be recessed into the surface of the wall with flush type. With electronic short-circuit and automatic overload protection protection type, this rotary dimmer concerns your safety. It obtained CE certificate as well. This rotary dimmer is SVHC (substances of very high concern) free too. What's more, it well satisfied the standard of EN 60669-2-1, EN 61000-6-3. It reaches IP20 degree of protection too. And it is mercury free.
