СКУ: LUCA1XFU
Моторен пускател TESYS U - модул 0,35-1,
-
Brand
Schneider Electric
-
Number of poles
3
-
Voltage type for actuating
EV000509
-
With ground fault protection function
TRUE
-
Short-circuit release function
EV003978
-
Rated control supply voltage Us at AC 50HZ
110
-
Rated control supply voltage Us at AC 60HZ
110
-
Rated control supply voltage Us at DC
110
-
Type of motor protection
EV001281
-
Initial value of the undelayed short-circuit release - setting range
18
-
End value adjustment range undelayed short-circuit release
18
-
Overload release current setting
0.35
-
Rated permanent current Iu
1.4
TeSys LRD thermal overload relay, 104A/1000V, thermal setting range 80-104A, tripping class 10A, for protection of 3-phase motors less than 0.06kW@400V. Differential device with phase failure and load unbalance detection. It provides a thermal adjustement dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons, a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing. Connection by screw clamp terminals, it connects directly to the bottom terminals of 3-pole contactors LC1D09-D38. Mounting on DIN rail or screw fixing, separated from the contactor, with use of a terminal block LAD7B106 (to be ordered separately). Multi standards certified (IEC, UL, CSA, CCC, EAC, ATEX, Marine).
