СКУ: 19001
Модулна Дефектнотокова защита Vigi NG125 2P - 63A - 300mA
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Version as emergency stop installation
FALSE
-
Version as reversing switch
FALSE
-
Suitable for front mounting centre
TRUE
-
Device construction
EV009211
-
Interlockable
FALSE
-
Version as maintenance-/service switch
FALSE
-
Degree of protection (IP), front side
EV006405
-
Suitable for front mounting 4-hole
TRUE
-
Motor drive integrated
FALSE
-
Suitable for intermediate mounting
FALSE
-
Suitable for floor mounting
FALSE
-
Motor drive optional
FALSE
-
Rated short-time withstand current lcw
1.5
-
Version as main switch
TRUE
-
Colour control element
EV000206
-
Suitable for distribution board installation
TRUE
-
Number of poles
4
-
Max. rated operation voltage Ue AC
500
-
Rated permanent current Iu
100
-
Type of control element
EV000421
-
Voltage release optional
TRUE
-
Number of auxiliary contacts as normally closed contact
-
Number of auxiliary contacts as change-over contact
-
Number of auxiliary contacts as normally open contact
-
Version as safety switch
TRUE
-
Rated operating voltage
500
-
Number of switches
4
This Acti9 NG125NA is a low voltage switch disconnector with free tripping for making and breaking under load. It has 3P+N with 4 protected poles. Its rated current is 1250A at 500VAC. It can be mounted on DIN rail for modular installation. Its width is 12 modules of 9mm. The degree of protection is IK05 and IP20 becoming IP40 once in modular enclosure. It is especially suitable for the modular enclosure incoming feeder with remote breaking (e.g. emergency cutoff). its service life is improved due to a good overvoltage withstand capacity, high limitation performances and a fast closure independent of the speed of actuation of the toggle. A test button allows to check the satisfactory operation of the tripping mechanism. It has a circuit breaker tripped indicator and the central manual control has 3 positions (ON, tripped on fault, open). The presence of the green strip guarantees physical opening of the contacts and allows operations to be performed on the downstream circuit in complete safety. This product is compliant with IEC/EN 60947-3.
