СКУ: 47302
Micrologic 6.0 H изкл. блок - LSIG - за NT изваждащ се
-
Brand
Schneider Electric
-
Rated control supply voltage Us at DC
24
-
Type of motor protection
EV014005
-
Voltage type for actuating
EV009206
-
With ground fault protection function
TRUE
-
Overload release current setting
252
-
Short-circuit release function
EV003977
-
Initial value of the undelayed short-circuit release - setting range
12600
-
End value adjustment range undelayed short-circuit release
94500
-
Rated permanent current Iu
6300
This is a basic frame for 4 poles Masterpact NT16H1 drawout circuit breaker. Masterpact NT is a comprehensive range of air circuit breakers designed to protect electrical systems from damage caused by overloads, short circuits and equipment ground faults. The breaking capacity (Icu) is 42kA rms at 440VAC 50/60Hz. The rated current is 1600A. This basic frame is compatible with any type of Micrologic control unit which has to be ordered separately. The basic frame must be associated with the corresponding chassis which has also to be ordered separately. With Micrologic control unit, Masterpact NT contributes to safety and energy efficiency. It can be equipped with a variety of optional functions and accessories. The dimensions are 358mm (W) x 322mm (H) x 277mm (D). It ensures compliance with international standards (IEC 60947), UL489, CCC, EAC and marine specifications.
