MF700 Butterfly Valve Actuator, On/Off or 3 Position Floating Control, 230 Vac, 700 Nm, SPDT Aux Switch + Heater, IP65 | Spark & Co
  • 3D
|

СКУ: MF700-230F

MF700 Butterfly Valve Actuator, On/Off or 3 Position Floating Control, 230 Vac, 700 Nm, SPDT Aux Switch + Heater, IP65

  • Brand
    Schneider Electric
  • Explosion-proof
    FALSE
  • Material housing
    EV000154
  • Degree of protection (IP)
    EV006419
  • Suitable for manual operation
    TRUE
  • Potential free switch contact
    FALSE
  • Adjustable position feedback signal
    TRUE
  • Regulation type splitrange
    FALSE
  • Regulation type modulating
    TRUE
  • Return at zero supply voltage
    FALSE
  • Self-adjusting travel length
    FALSE
  • Auxiliary contacts optional
    FALSE
  • Adjustable operating range
    TRUE
  • Allowable relative humidity
  • Deactivated when closed
    FALSE
  • Auxiliary contacts
    FALSE
  • End contacts
    EV000494
  • With top flange direct mount according to ISO 5211
    FALSE
  • Automatic travel recognition
    TRUE
  • With mechanical setting indicator
    TRUE
  • Supply voltage
    EV021685
  • Depth
    93
  • Degree of protection (NEMA)
    EV000600
  • Height
    105
  • Width
    128
  • Connection to stop valve
    EV000494
  • Model
    EV010029
  • Position reporting system
    EV021560
  • With safety function
    FALSE
  • Length of connection cable
    1
  • Transmission
    EV006116
  • Regulation type on/off
    TRUE
  • Operating time
    75
  • Suitable for air accessory
    TRUE
  • Max. angle of rotation
    95
  • Suitable for valve
    FALSE
  • Ambient temperature
    -30
  • Type of safety function
    EV008419
  • Max. electric power input
    5.5
  • Control signal
    EV021430
  • Torque
    10
  • Energy consumption in operation
    3.5

The MG350V globe valve actuators are non-spring return electromechanical actuators for the control of two-way and three-way globe valves. They are use for fan coils, unit ventilators, reheat, cooling units, perimeter heating, and other applications. The actuators are compatible with older field-installed VB-9 globe valves as wall as other valves. Auto-calibration provides precise control by scaling the input signal to match the exact travel of the valve stem. Power Supply: 24 Vac. Input Signal: 2 … 10 Vdc, 0… 10 Vdc, 4 … 20 mA. Position Feedback Output Signal: 2…10 Vdc, 0…5 Vdc, Field selectable. Force: 350 N. Max. Stroke 16.5 mm. The stem adapter and stem adapter jam nut are included with the actuator. Graduated position indicator showing open to close with end point indicators. Removable terminal block, AWG 12 … 24, meets the requirements of cUL without the need of an electrical earth ground connection.
