СКУ: 33192

Ключалка, MasterPact NT/NW, ComPacT NS, изваждаем, 1 ключалка Ronis с 2 ключа, с обозначена комбинация EL24315, резервна част

  • Brand
    Schneider Electric
  • Device construction
    EV009211
  • Number of auxiliary contacts as normally closed contact
  • Number of auxiliary contacts as change-over contact
  • Number of auxiliary contacts as normally open contact
  • Motor drive optional
    FALSE
  • Degree of protection (IP)
    EV006415
  • Number of poles
    4
  • Rated permanent current Iu
    630
  • Type of electrical connection of main circuit
    EV008864
  • Complete device with protection unit
    FALSE
  • DIN rail (top hat rail) mounting optional
    FALSE
  • Rated voltage
    690
  • Position of connection for main current circuit
    EV007926
  • Integrated earth fault protection
    FALSE
  • Suitable for DIN rail (top hat rail) mounting
    FALSE
  • Type of control element
    EV000554
  • With switched-off indicator
    TRUE
  • With integrated under voltage release
    FALSE
  • Motor drive integrated
    TRUE
  • Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
    50

It's a fixture kit used for cable interlocking for MasterPact NT in drawout version. For cable interlocking, the circuit breakers may be mounted one above the other or side-by-side. It may be mounted on the left or right-hand side of the chassis. The interlocked devices may be 3 poles or 4 poles, and have different ratings and sizes. This device inhibits opening of the cubicle door when the circuit breaker is in "connected" or "test" position.
