СКУ: 16332

КАТОДЕН ОТВОДИТЕЛ PRD1 25R 3P N 350V WITH R

  • Brand
    Schneider Electric
  • Degree of protection (IP)
    EV006405
  • Integrated short-circuit protection
    FALSE
  • System configuration TN-C
    TRUE
  • Leakage-current free
    FALSE
  • System configuration DC
    FALSE
  • System configuration TN
    FALSE
  • System configuration TT
    FALSE
  • Signalling at the device
    EV000428
  • Nominal voltage AC
    400
  • Max. discharge surge current (8/20)
    50
  • Max. conductor cross section solid (solid, stranded)
    35
  • System configuration TN-C-S
    FALSE
  • Mounting method
    EV005503
  • System configuration other
    FALSE
  • With remote signalling contact
    TRUE
  • Integrated backup fuse
    FALSE
  • Category type 2
    FALSE
  • Construction size
    EV006974
  • System configuration TN-S
    TRUE
  • Voltage protection level
    2.5
  • Max. conductor cross section flexible (fine-strand)
    25
  • Nominal discharge surge current (8/20)
    35
  • System configuration IT
    TRUE
  • Number of conductors (without earthing)
    1
  • Max. continuous voltage AC
    440

This Acti9 PRD1 25r product is a modular surge arrester protecting 1P electrical installations against direct lightning strikes. The Imax maximum discharge current is 40kA .The In nominal discharge current is 25kA. The Type 1 surge arrester is recommended for electrical installations in the service sector and industrial buildings protected by a lightning conductor. It also provides type 2 protection and protect the electrical installation by finely clipping the lightning wave overvoltage. The surge arresters with "r" indication have remote transfer of the information "Cartridge to be replaced". The Uc maximum continuous operating voltage in common mode (between phase and earth) is 350VAC. The Up Voltage protection level in common mode (between phase and earth) is 1.5kV. The Ue rated operational voltage is 230VAC +/- 10%. The product colour is anthracite grey (RAL7016).The dimensions are (W) 36mm x (H) 90mm x (D) 71mm. The weight is 334g. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 80°C. This product is compliant with EN 61643-11 and IEC 61643-11 standards.
