СКУ: C254MG200D
Изключвателно устройство TM200G DC, ComPacT NSX250 DC, 4 полюса, термомагнитни защити, генераторна защита, 200A rating
-
Brand
Schneider Electric
-
Number of poles
3
-
Rated permanent current Iu
250
-
Voltage type for actuating
EV009206
-
With ground fault protection function
FALSE
-
Short-circuit release function
EV003978
-
Initial value of the undelayed short-circuit release - setting range
1250
-
End value adjustment range undelayed short-circuit release
2500
-
Type of motor protection
EV001281
-
Overload release current setting
175
This ComPacT NSX160N is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 160A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 4 poles version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX160N is part of Schneider Electric EcoStruxure Power architecture.
