изключвателно устройство TM100G, ComPacT NSX100/160, 4 полюса 4D (neutral protected), термомагнитни защити, генератор, 100A | Spark & Co
  • 3D
|

СКУ: C104MG100

изключвателно устройство TM100G, ComPacT NSX100/160, 4 полюса 4D (neutral protected), термомагнитни защити, генератор, 100A

  • Brand
    Schneider Electric
  • Rated permanent current Iu
    40
  • Number of poles
    4
  • Rated control supply voltage Us at DC
    24
  • Type of motor protection
    EV014005
  • Voltage type for actuating
    EV009206
  • With ground fault protection function
    TRUE
  • Short-circuit release function
    EV003977
  • Initial value of the undelayed short-circuit release - setting range
    60
  • End value adjustment range undelayed short-circuit release
    600
  • Overload release current setting
    18

This ComPacT NSXm device is a 4 poles switch disconnector designed to optimize space and breaking capacity. The rated current (In) is 160A. The rated short-circuit withstand current (Icw) is 1500A rms for 1s. The operational voltage is 440VAC 50/60Hz. Power connections are compression lugs or busbar connections. The product can be installed on a DIN rail or a mounting plate. It embeds new spring type auxiliaries externally visible. The dimensions are 108mm (W) x 137mm (H) x 80mm (D). It ensures compliance with international standards (IEC 60947/CCC/EAC) and marine specifications. ComPacT NSXm is part of the global Schneider Electric Environmental Program.
