СКУ: C6334A570

изключвателно устройство MicroLogic Vigi 4.3AL, ComPacT NSX630, 3 полюса, електронни основни защити, аларма към утечка на земя, 570A

  • Brand
    Schneider Electric
  • Type of electrical connection of main circuit
    EV000415
  • Version as emergency stop installation
    FALSE
  • Version as reversing switch
    FALSE
  • Device construction
    EV009211
  • Version as safety switch
    FALSE
  • Degree of protection (IP), front side
    EV006405
  • Suitable for front mounting 4-hole
    TRUE
  • Number of switches
    1
  • Motor drive integrated
    FALSE
  • Suitable for intermediate mounting
    FALSE
  • Suitable for front mounting centre
    FALSE
  • Version as main switch
    TRUE
  • Interlockable
    TRUE
  • Version as maintenance-/service switch
    TRUE
  • Colour control element
    EV000206
  • Suitable for distribution board installation
    TRUE
  • Number of poles
    4
  • Suitable for floor mounting
    TRUE
  • Rated permanent current Iu
    630
  • Rated permanent current at AC-23, 400 V
    630
  • Type of control element
    EV000421
  • Motor drive optional
    TRUE
  • Voltage release optional
    TRUE
  • Number of auxiliary contacts as normally closed contact
  • Number of auxiliary contacts as change-over contact
  • Number of auxiliary contacts as normally open contact
  • Rated short-time withstand current lcw
    7.5
  • Rated operating voltage
    750

This MicroLogic 6.3 E-M (Energy) is a 3 poles 3d electronic trip unit used on ComPacT NSX 400/630 circuit breakers. This 320A rating electronic trip unit is an optimum choice for motor protection applications. It embeds an adjustable long time protection against overloads. It provides also an adjustable short-time protection and a fixed instantaneous protection against short-circuits. It offers a phase unbalance or phase loss protection, and an additional and adjustable ground fault protection. MicroLogic 6.3 E-M indicates overloads with Alarm LEDs. The green Ready LED flashes if the circuit breaker is ready to trip. MicroLogic 6.3 E-M is equipped with a display module that gives energy measurement and allows fine adjustment settings. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.
