СКУ: A9L20421

IPRD 20R 20 KA 460V 4P IT с комуникация

  • Brand
    Schneider Electric
  • Degree of protection (IP)
    EV006405
  • Integrated short-circuit protection
    FALSE
  • System configuration TN-C
    TRUE
  • Leakage-current free
    FALSE
  • System configuration DC
    FALSE
  • System configuration TN
    FALSE
  • System configuration IT
    FALSE
  • Number of conductors (without earthing)
    3
  • System configuration TT
    FALSE
  • System configuration TN-S
    FALSE
  • Signalling at the device
    EV000428
  • Nominal voltage AC
    400
  • System configuration TN-C-S
    FALSE
  • Mounting method
    EV005503
  • System configuration other
    FALSE
  • Integrated backup fuse
    FALSE
  • Category type 2
    TRUE
  • Max. continuous voltage AC
    350
  • With remote signalling contact
    FALSE
  • Voltage protection level L-N
    1.1
  • Max. overcurrent protection device, series connection (fuse)
    80
  • Voltage protection level N-PE
    1.4
  • Short-circuit breaking capacity (Isccr)
    50
  • Voltage protection level
    1.4
  • Max. overcurrent protection device, parallel connection (fuse)
    40
  • Nominal discharge surge current (8/20)
    5
  • Max. discharge surge current (8/20)
    20
  • Max. conductor cross section solid (solid, stranded)
    25
  • Max. conductor cross section flexible (fine-strand)
    16
  • Construction size
    EV007000

This Acti9 iPRD surge arrester protects 2P installations. It allows quick replacement of damaged cartridges. This Type 2 device is recommended for medium risk level and incoming panel board. It can be turned over to allow the phase/neutral/earth cables to enter through either the top or the bottom. The associated circuit breaker Isc breaking capacity can go up to 50kA. This Acti9 iPRD20 is compatible with TT and TN-S earthing system. The Uc maximum continuous operating voltage is 350VAC in common mode (L/PE or N/PE). The Up Voltage protection level is 1.1kV in common mode (L/PE or N/PE). The Ue rated operational voltage is 230VAC +/- 10%. The product colour is white (RAL9003).The dimensions are (W) 36mm x (H) 85mm x (D) 69mm. The weight is 216g. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 85°C. This product is compliant with EN 61643-11 and IEC 61643-11 standards.
