Cen.pla. USB charger TPb ant SysM

Schneider Electric's Merten insert offers a USB-C PD charger with a power output of 65W, and is dedicated for any indoor environment and in-wall power supply. This charger is equipped with advanced charging technology USB-C Power Delivery (PD), enhancing the battery charging performance. It smartly negotiates the fastest power rate that the device can handle, and supports all the latest battery charging technologies. It is also backwards compatible. The charger enables optimal fast-charge to laptops, smartphones and devices like earbuds, headsets, and others. It is an OVC III device that includes overheat, short circuit, inrush current and overcurrent protection. The USB-C provides maximum 65W fast charge power for laptops and tablets. It supports PD and proprietary protocols: 5V 3A 15W | 9V 3A 27W | 12V 3A 36W | 15V 3A 45W | 20V 3.25A 65W. The high durability USB ports allow for >10K mating cycles. It has 2 screw terminals with pozidriv No 1 screwhead. It has good wiring capacity for rigid and flexible cable with 2 x 0.75 - 2 x 2.5 sq.mm cable cross section. The wire stripping length is 7 - 9 mm. The standby power is <0.08W, and the input voltage is 220-240VAC at 50-60Hz. The product lifespan is 30,000 hours with output power 65W by 25°C. Its matching mounting box can be recessed into the surface of the wall with flush type. The dimensions of the product are (W) 71mm x (H) 71mm x (D) 30mm, with an embedding depth of 30.8 mm. The USB charger is made of PC (polycarbonate) GF10 FR, making it as resistant as possible. It reaches IP20 and IK04 degrees of protection. The operation temperature between 0°C to 40°C. System M range is based on 4 different surfaces and materials. With 9 different design variations and over 280 functions, the system can meet any customer demand. The product has a declaration of Conformity (EU), CB report. It complies with EN-IEC 62368-1, IEC 61000-3-2, IEC 61000-3-3, EN 50032, EN 55035, EcoDesign 2019/1782/EC, EN 50563, RoHS, and REACH standards.
