СКУ: HMIET6401
7" сезорен екран, 16M цвята, COM x 2, USB вход, RTC, DC24V
-
Brand
Schneider Electric
-
Supporting protocol for SERCOS
FALSE
-
Radio standard GPRS
FALSE
-
Supporting protocol for INTERBUS-Safety
FALSE
-
Supporting protocol for AS-Interface Safety at Work
FALSE
-
Radio standard GSM
FALSE
-
Radio standard UMTS
FALSE
-
Supporting protocol for DeviceNet Safety
FALSE
-
Supporting protocol for Foundation Fieldbus
FALSE
-
Supporting protocol for SafetyBUS p
FALSE
-
Supporting protocol for PROFINET CBA
FALSE
-
Supporting protocol for PROFINET IO
FALSE
-
Supporting protocol for PROFIsafe
FALSE
-
Supporting protocol for ASI
FALSE
-
Radio standard Bluetooth
FALSE
-
Supporting protocol for PROFIBUS
FALSE
-
Radio standard Wi-Fi 802.11
FALSE
-
Supporting protocol for KNX
FALSE
-
Supporting protocol for INTERBUS
FALSE
-
Supporting protocol for DeviceNet
FALSE
-
Suitable for safety functions
FALSE
-
Supporting protocol for Data-Highway
FALSE
-
Supply voltage DC
24
-
Supporting protocol for LON
FALSE
-
Supporting protocol for SUCONET
FALSE
-
Degree of protection (IP), front side
EV008925
-
Rail mounting possible
TRUE
-
Supporting protocol for other bus systems
FALSE
-
Number of HW-interfaces parallel
-
Number of interfaces PROFINET
-
Number of function buttons, programmable
-
Number of HW-interfaces other
-
Number of HW-interfaces serial TTY
-
With numeric keyboard
FALSE
-
Number of HW-interfaces Wireless
-
With alpha numeric keyboard
FALSE
-
Number of buttons with LED
-
With message system (incl. buffer and confirmation)
FALSE
-
Process value representation (output) possible
TRUE
-
Supporting protocol for EtherNet/IP
TRUE
-
With SW interfaces
TRUE
-
Number of system buttons
-
Supporting protocol for TCP/IP
TRUE
-
Supporting protocol for Modbus
TRUE
-
With message indication
TRUE
-
Number of HW-interfaces USB
2
-
Number of password levels
-
With printer output
FALSE
-
Process default value (input) possible
TRUE
-
Additional software components, loadable
TRUE
-
Touch technology
EV013187
-
Voltage type of supply voltage
EV000509
-
Number of pixels, horizontal
320
-
With colour display
TRUE
-
Supporting protocol for CAN
TRUE
-
IO link master
TRUE
-
Number of HW-interfaces RS-422
-
Wall mounting/direct mounting
TRUE
-
Number of HW-interfaces RS-485
1
-
Number of pixels, vertical
240
-
Number of HW-interfaces industrial Ethernet
1
-
Number of HW-interfaces RS-232
1
-
Screen diagonal
5.7
-
Built-in depth
76.22
-
Width of the front
163
-
Height of the front
129.4
-
Number of grey-scales/blue-scales of display
-
Degree of protection (NEMA), front side
EV014040
-
With recipes
FALSE
-
Number of online languages
4
-
Operating temperature
-20
-
Useful project memory/user memory
128
-
Type of display
EV000433
-
Number of colours of the display
65536
HMIET6600 is an essential touchscreen panel of the Schneider Electric's Easy Harmony ET6 range. This single touch resistive HMI Ethernet panel has high resolution and more colors. This HMI interface is 12.1 inch wide with 16 million colors and 1,280 x 800 pixel resolution (WXGA). It is powered by Vijeo Designer Basic software for intuitive user experience. It has a 800 MHz ARM Cortex-A8 CPU, 256 MB as system and application memory, 128 KB nonvolatile memory. This HMI ET6 supports Ethernet port, COM1 (RS-232C), COM2 (RS-422/485), 1x USB 2.0 Type A, and 1x USB 2.0 Micro-B port. Its dimensions are 310.5mm (width) x 232.5mm (height) x 50mm (depth) and weighs 1.62Kg. This is intended for industries like Packaging, HVAC, Pump, Electronics, battery, machine tools and material working etc. It conforms to standards like EN (61000-6-4, 61000-6-2, 61131-2), UL 61010-2-201, CSA C22.2 No 61010-2-201 and certifications like UL, CE, KC, EAC, China RoHS, REACH. The maintenance accessories (installation fastener screw, power supply connector, battery, etc.) and external options (USB download cable, USB extension cable, screen protection sheet, etc.) are available with HMI ET6. It is designed for panel mounting by 4 or 6 fastener screws (the quantity of screws depends on screen size). This range is designed with high resolution screen, more colors, and Ethernet capability to enable OEMs to optimize their HMI design and investment. The degree of protection is IP65F.
