СКУ: HMIET6700
15" сезорен екран, 16M цвята, COM x 2, ETH x 1, USB host / вход, RTC, DC24V
-
Brand
Schneider Electric
-
Degree of protection (IP), front side
EV006421
-
Built-in depth
47
-
Supporting protocol for SERCOS
FALSE
-
Radio standard GPRS
FALSE
-
Supporting protocol for INTERBUS-Safety
FALSE
-
Supporting protocol for AS-Interface Safety at Work
FALSE
-
Radio standard GSM
FALSE
-
Radio standard UMTS
FALSE
-
Supporting protocol for DeviceNet Safety
FALSE
-
Supporting protocol for EtherNet/IP
FALSE
-
Supporting protocol for Foundation Fieldbus
FALSE
-
Supporting protocol for SafetyBUS p
FALSE
-
Voltage type of supply voltage
EV000461
-
Supporting protocol for PROFINET CBA
FALSE
-
Supporting protocol for PROFINET IO
FALSE
-
Supporting protocol for PROFIsafe
FALSE
-
Supporting protocol for ASI
FALSE
-
Radio standard Bluetooth
FALSE
-
Supporting protocol for PROFIBUS
FALSE
-
Radio standard Wi-Fi 802.11
FALSE
-
Supporting protocol for TCP/IP
FALSE
-
Supporting protocol for KNX
FALSE
-
Supporting protocol for CAN
FALSE
-
Supporting protocol for INTERBUS
FALSE
-
IO link master
FALSE
-
Supporting protocol for DeviceNet
FALSE
-
Rail mounting possible
FALSE
-
Supporting protocol for Modbus
FALSE
-
Supporting protocol for Data-Highway
FALSE
-
Supporting protocol for LON
FALSE
-
Supporting protocol for SUCONET
FALSE
-
Supporting protocol for other bus systems
FALSE
-
With message indication
FALSE
-
Number of HW-interfaces parallel
-
Number of interfaces PROFINET
-
Number of function buttons, programmable
-
Number of HW-interfaces other
-
Number of HW-interfaces serial TTY
-
With numeric keyboard
FALSE
-
Number of HW-interfaces Wireless
-
With alpha numeric keyboard
FALSE
-
Number of buttons with LED
-
With message system (incl. buffer and confirmation)
FALSE
-
Process default value (input) possible
FALSE
-
Additional software components, loadable
FALSE
-
Number of system buttons
-
Number of grey-scales/blue-scales of display
16
-
Type of display
EV005759
-
Number of password levels
-
With printer output
FALSE
-
Touch technology
EV013187
-
With SW interfaces
FALSE
-
Operating temperature
-
With colour display
TRUE
-
Wall mounting/direct mounting
TRUE
-
Number of HW-interfaces RS-485
1
-
Number of HW-interfaces RS-232
1
-
Number of HW-interfaces industrial Ethernet
-
Process value representation (output) possible
FALSE
-
With recipes
FALSE
-
Suitable for safety functions
TRUE
-
Screen diagonal
10
-
Number of online languages
-
Useful project memory/user memory
1000000
-
Supply voltage AC 50 Hz
-
Number of colours of the display
16000000
-
Supply voltage DC
-
Number of HW-interfaces RS-422
1
-
Number of pixels, horizontal
1024
-
Width of the front
271
-
Height of the front
201
-
Number of pixels, vertical
600
-
Number of HW-interfaces USB
1
HMIET6401 is an essential touchscreen panel of the Schneider Electric's Easy Harmony ET6 range. This single touch resistive HMI Serial panel has high resolution and more colors. This HMI interface is 7 inch wide with 16 million colors and 800 x 480 pixel resolution (WVGA). It is powered by Vijeo Designer Basic software for intuitive user experience. It has a 800 MHz ARM Cortex-A8 CPU, 256 MB as system and application memory, 128 KB nonvolatile memory. This HMI ET6 supports COM1 (RS-232C), COM2 (RS-422/485), 1x USB 2.0 Micro-B port. Its dimensions are 205.5mm (width) x 150.5mm (height) x 45mm (depth) and weighs 0.60Kg. This is intended for industries like Packaging, HVAC, Pump, Electronics, battery, machine tools and material working etc. It conforms to standards like EN (61000-6-4, 61000-6-2, 61131-2), UL 61010-2-201, CSA C22.2 No 61010-2-201 and certifications like UL, CE, KC, EAC, China RoHS, REACH. The maintenance accessories (installation fastener screw, power supply connector, battery, etc.) and external options (USB download cable, USB extension cable, screen protection sheet, etc.) are available with HMI ET6. It is designed for panel mounting by 4 or 6 fastener screws (the quantity of screws depends on screen size). This range is designed with high resolution screen, more colors, and Ethernet capability to enable OEMs to optimize their HMI design and investment. The degree of protection is IP65F.
